concrete mixing station starting up steps

concrete mixing station starting up steps

1. Before the operation of mixing station, ensure the switch power cabinet in full closing.

2 .voltage rotating power cabinet doors on the universal switch, observe the three-phase voltage is normal. VAB=VBC=VCA=380V + 38V, V0=0V, said the three-phase voltage is normal, if not normal, please check the network voltage.

3. to ensure the normal three-phase voltage, power knob rotary power cabinet, power on the operation panel at the moment indicator should be in a state of lights, instrument power on.

4. in the power cabinet door, press the start button at the air compressor, air compressor start button lights in the lighting state.

5. turn on the computer and enter the desktop of the computer system. Double click on the three one icon on the desktop (that is, running the monitor program). In the monitoring program, click the management system, operation management program.

6. to observe the alarm window monitoring program if the alarm information, if any, please according to the alarm information and troubleshooting. Ensure the alarm window without the alarm information, the production of concrete according to the production requirements.

website: www.haomeimachinery.com  to see more information about different parts of concrete batching plant,  and if you have more question about it, feel free to contact us, we will reply you as soon as possible.
