4.0m3 Self Loading Concrete Mixer Machine
- Condition: New
- Delivery port: Qingdao or Tianjin port, China
- Payment term: L/C, T/T
- Guarantee period: 12 months
- Delivery time: 10-15 days after received deposit
- Installation time: 20days
Self loading concrete mixer machine is an efficient concrete solution which can automatically fulfill the work of loading, mixing, transportation and unloading. Thus it can replace 4-6 workers and significantly cut the labor cost. The compact design makes it flexible in narrow and limited space. Haomei self loading concrete mixers are available in 1.2cbm, 1.6cbm, 2.0cbm, 2.6cbm, 3.0cbm, 3.5cbm, 4.0cbm, 5.5cbm and 6.5cbm to meet demands of various projects. Haomei self loading concrete mixer truck will finish per batch in 12-15 minutes, one hour can finish at least 4 batches.
The configuration of 4m3 self loading mixer machine are:
| Equipment Model | 4.0 cubic self loading concrete mixer |
| Drum geometrical capacity | 6000L |
| Discharge Capacity | 4000L |
| Engine Model | YCD4J22G |
| Rated Power | 85kw |
| Gear box model | ZL-280 power shift transmission |
| Gear | 4 forward 4 back |
| Fuel tank | 230L |
| Total hydraulic system capacity | 170 liters |
| Oil tank | 16 liters |
| Reducer | KY07-5-J |
| Hydraulic Pump | Parker pump |
| Hydraulic Motor | HAA2FM56/61W-VTD527 |
| Water tank | 660L |
| Water supply | Time relay |
| Overall dimensions(L*W*H) | 7500*2850*3600 |
| Wheelbase (mm) | 2450 |
| Curb Weight (kg) | 8500 |
| Drive Form | Torque converter |
| Drum rotary | 290º |
| Drum Mixing Speed (r/min) | 17 |
| Max.Speed (km/h) | 35 |
| Maximum grade | 30º |
| Maximum turning radius (mm) | 4000 |
| Minimum ground clearance (mm) | 330 |
The advantage of self loading concrete mixer machine are:
