Portable Concrete Mixer with Pump

Portable diesel concrete mixer with pump is featured by the combination of mixing and conveying of concrete together, which can save labors and reduce labor intensity. Portable concrete mixer with pump can be applied to varieties of construction projects to help you expand business scope. Mobile Concrete mixer with can transport concrete to places that labors or tractors have no access to, which is undoubtedly a good choice for the construction of civil house, water conservancy, rural roads and ground works.

Mobile concrete mixer with pump is a widely-used concrete mixing and concrete pumping machine in the market. It is becoming more and more well-received by customers at home and abroad due to its unique design. Equipped with wheels, the mobile type of concrete pump and mixer can be pulled by trailer. Moreover, it has obvious advantages of smooth running and easy operation. In general, it is used in the underfloor heating project, house building and so forth. Haomei Machinery has exported our mobile concrete mixer pump to more than 30 countries.

Technical parameters of portable diesel concrete mixer with pump:

Items	Units	ABJZ30C	ABJZ40C	ABJS40C-JS500	ABJS40C-JS750
Max. theo. concrete output(L./H)	M3/h	30	40	40	40
Mixer rated feed capacity	m3	0.56	0.56	0.56	0.56
Mixer rated discharge capacity	m3	0.35	0.45	0.5	0.75
Max.concrete pumping pressure(H./L.)	MPa	10	10	8	8
Distribution valve type		S  Valve
Concrete cylinder diameter×stroke	mm	Φ140×1000	Φ180×1000	Φ200×1000	Φ200×1000
Hopper capacity	L	400	400	400	400
Outlet diameter	mm	Φ150	Φ150	Φ180	Φ180
Diesel engine model			Weichai	Weichai	Weichai
Electrical engineering power	KW	37	82	129	129
Rotate speed	r/min	1480	2200	2200	2200
Circuit type		Open circuit
Pumping system pressure	MPa	26	32	32	32
Mixing system pressure	MPa	6-8	6	6	6
Capacity of oil tank	L	260	350	350	350
Max. Theoretical Vertical/Horizontal Conveying Distance	m	120/300	120/500	120/500	120/500
Max. aggregate diameter	mm	Slick/scree:10/20	Slick/scree:40/50	Slick/scree:40/50	Slick/scree:40/50
Inside diameter of delivering pipe	mm	Φ100	Φ125	Φ125	Φ125
Dimensions：length×width×height	mm	4500x1750x1600	600x2300x3150	7500x2300x3150	7500x2300x3150
Total weight	kg	3000	4500	5000	5500

Key Benefits of Mobile Concrete Mixer with Pump

1. Seamless discharge:
This mixer pumps discharge the liquid concrete seamlessly, and they bind firmer. In other words, the structure gets firmer and more robust. if the concrete gets laid in a constant flow. The constant flow will take minimal time to complete the task of putting the concrete.
2. Reduce the wastage of resources:
The machine can put the concrete right at the coveted place. It minimizes the wastage of the resources that usually happens with the scattering of the concrete when put through the crane and bucket.
3. Reduction in the waste of man hours:
When the mixing is done manually, significant time lapses between the time 2 layers of concrete gets laid. On the long run, these time spans account to a span of a few weeks. The construction companies can save time,because the usage of concrete mixer pump will improve the working efficiency.

After-sales Service of portable concrete mixer with pump
For concrete mixer pump sold, we would provide customers considerate after-sales service, including checking, repairing, testing, debugging equipment etc. If the equipment need urgent repairing, we can help guide how to repair it long-distance or arrange engineer to check it on construction site. For solving customers’ problems, we have established more than 6 offices all over the world. LBS centers are also available in those countries: Indonesia, Malaysia, Pakistan, Uzbekistan, Philippines etc. Therefore, if you purchase one from us, there is no worry about its service.
