HDT5350THB-42/45 Concrete Pump

Tel:+86-371-65621392
  • Condition: New
  • Delivery port: Qingdao or Tianjin port, China
  • Payment term: L/C, T/T
  • Guarantee period: 12 months
  • Delivery time: 10-15 days after received deposit
  • Installation time: 20days
Product Details

portable cement mixer with pump Hydraulic System Features

Free flowing closed hydraulic driving system formed by double concrete pump confluency has such advantages as large output power with small wearing, and smooth reversal with no impact.Intelligent control system makes driving oil flow incessantly and directly enter driving oil cylinder without any loss.

No fussy middle reversal control valve piece lessens reversal impact, avoids too high oil temperature and simultaneously facilitates servicing.Compared with large-oil-tank open system, closed system needs a smaller tank and the tank oil liquid flows gently with no easy emulsifying;Unique buffer technology can lower the system’s high-pressure peak value. In spite of high-output-flow situation, the aggregate carrying pipe vibrates little with the tail pipe steady. Electric proportional variable adjustment makes concrete output flow pour according to actual needs.

HDT5350THB-42/45 portable diesel concrete mixer with pump

Adopts international buying with key parts all from international famous brand which have the following features:
1.Original imported GERMANY HBC wireless remote-control device with light weight and handy carrying can enable aggregate carrying pipe to pump truck for concrete take position accurately simply by manual control.
2.pumping capacity can be infinitely variably controlled. pump truck expanding speed can be infinitely controled through quicken-slow device.
3.boom slewing speed can be infinitely controled .
4.it’s equipped with emergency brake device and diesel engine auto-control-speed device to lower oil-consumption.original imported GERMANY STEIBEL transfer case and REXROTH pump group;original imported slewing reductor and slewing motor;original imported GERMANY HAWE proportional multiway valve;original imported GERMANY REXROTH valve and valve from ITALY oil-control companies;electric control box adopting totally imported parts while control modules like PLC are all products from GERMANY SIEMENS.



HDT5350THB-42/45 concrete truck pump

Haomei putzmeister concrete pump hopper truck structure receives has on boom’s fatigue life on HAOMEI's drawing on advanced experience both at home and abroad. Meantime, the company optimized hydraulic system’s design, adopted latest free fluid technique, greatly lessened pumping reversal’s impact on boom,and won many patents on concrete pump truck structure’s optimization and hydraulic system’s design. Perfect product quality control, perfect product making, and absolutely adequate quality inspection make HAOMEI pump truck achieve CHINA’s leading level and international advanced level. Pump system adopts steel plates all from SWEDISH SSAB, which have been treated by high-strength coldrolling with yield strength beyond 900Mpa, to ensure boom system with high-strength and light weight. The system’s aggregate carrying pipe,landing leg,and oil tank,etc. all have been treated by 100% stess removing after welding. Every welding seam has been treated by 100% nondestructive evaluation or X radial check to avoid any tiny defect and to make the machine more enduring.

The boom system adopts slewing bearing from GERMANY ROTHE ERDE or imported ITALY product, which have higher strength and longer using life with texture to be 42CrMo.Accurate data support from finite element analysis and dynamics simulation analysis act as design basis to ensure boom system with a scientific structure and excellent property. Stess and strain test are conducted by national test center to verify the agreement between boom structure calculated analysis result and actual working condition.

Basic information of self loading concrete mixer with pumps

Specification Value
output in theory(m3/h) 125
index of the pump carry capacity(Mpa.m3/h) 586
theoretic pumping pressure(Mpa) 8.5
bucket volume(L) 700
height of top surface of bucket(mm) 1400
model of distribution valve(S) S Valve
max. operation radius(m) 38 40.7
max. operation height(m) 41.8 44.7
max. operation depth(m) 29 31.3
open height of boom(mm) 8600 8495
distance between front landing legs(mm ) 8820 9550
distance between rear landing legs(mm) 8500 9550
distance between front & rear landing legs(mm) 8490 9190
diameter of delivery pipe(mm) 125
length of hose pipe(m) 3
rotary range of boom 365°
quantity of boom 4 5
rotary angle of each boom(°) 92/180/180/240 91/180/180/180/270
wire line control distance(m) 33
romote control distance(m) 200
max. speed(km/h) 85 80
min. turn radius(mm) 12100
brake distance(m) 10
approach angle(°) 16
departure angle(°) 11
chassis model HOWO ZZ5307N4647C
wheel base between the first & the second axle(mm) 4600
wheel base between the second & the third axle(mm) 1350
front tread(mm) 2022
rear tread(mm) 1830
max. engine output power(kw) 275(2200r/min)
max. engine output torque(n.m) 1500 /(1100~1600 r/min)
max, gradient ability(%) 37 35
fuel consumption(L/100km) 38 40
(××)out dimension(L×W×H)mm 13650×2490×3960 13300×2500×4000
total weightkg 35000 40000
