HDT5401THB-48/52 Concrete Pump

Tel:+86-371-65621392
  • Condition: New
  • Delivery port: Qingdao or Tianjin port, China
  • Payment term: L/C, T/T
  • Guarantee period: 12 months
  • Delivery time: 10-15 days after received deposit
  • Installation time: 20days
Product Details

HDT5401THB-48/52 Concrete pump



HDT5401THB-48/52 concrete pump for sale adopts international buying with key parts all from international famous brand which have the following features:

1.Original imported GERMANY HBC wireless remote-control device with light weight and handy carrying can enable aggregate carrying pipe to take position accurately simply by manual control.

2.pumping capacity can be infinitely variably controlled. pump truck expanding speed can be infinitely controled through quicken-slow device.

3.boom slewing speed can be infinitely controled .

4.it’s equipped with emergency brake device and diesel engine auto-control-speed device to lower oil-consumption.original imported GERMANY STEIBEL transfer case and REXROTH pump group;original imported slewing reductor and slewing motor;original imported GERMANY HAWE proportional multiway valve;original imported GERMANY REXROTH valve and valve from ITALY oil-control companies;electric control box adopting totally imported parts while control modules like PLC are all products from GERMANY SIEMENS.

Hydraulic System Features of concrete pump truck

Free flowing closed hydraulic driving system formed by double pump confluency has such advantages as large output power with small wearing, and smooth reversal with no impact.Intelligent control system makes driving oil flow incessantly and directly enter driving oil cylinder without any loss.

No fussy middle reversal control valve piece lessens reversal impact, avoids too high oil temperature and simultaneously facilitates servicing.Compared with large-oil-tank open system, closed system needs a smaller tank and the tank oil liquid flows gently with no easy emulsifying;Unique buffer technology can lower the system’s high-pressure peak value. In spite of high-output-flow situation, the aggregate carrying pipe vibrates little with the tail pipe steady. Electric proportional variable adjustment makes concrete output flow pour according to actual needs.

Technical parameters of concrete pump

Specification Value
output in theory(m3/h) 125
index of the pump carry capacity(Mpa.m3/h) 586
theoretic pumping pressure(Mpa) 8.5
bucket volume(L) 700
height of top surface of bucket(mm) 140
model of distribution valve(S) valve
max. operation radius(m) 43.7 47.8
max. operation height(m) 47.7 51.8
max. operation depth(m) 34.3 39.8
open height of boom(mm) 9065 9400
distance between front landing legs(mm ) 9780 10295
distance between rear landing legs(mm) 9860 10650
distance between front & rear landing legs(mm)
9470/10310
diameter of delivery pipe(mm) 125
length of hose pipe(m)
 3
rotary range of boom 365°
quantity of boom 5
rotary angle of each boom(°) 91/180/180/180/270 90/180/180/180/270
wire line control distance(m) 33
romote control distance(m) 200
max. speed(km/h) 85 80
min. turn radius(mm) 12000 12500
8800(m) 10
approach angle(°) 16
departure angle(°) 11
chassis model HOWO ZZ5437S4667C
wheel base between the first & the second axle(mm) 1800
wheel base between the second & the third axle(mm) 4600 5000
front tread(mm) 1350
rear tread(mm) 2022
max. engine output power(kw) 275(2200r/min)
max. engine output torque(n.m) 1500 /(1100~1600 r/min)
max, gradient ability(%) 37
fuel consumption(L/100km) 40
(××)out dimension(L×W×H)mm 13300×2500×4000 13990×2500×4000
total weightkg 40000 42000
